Product: 88TK05C-E GJR2393200R1220 ABB Station-Bus Coupling Module

Description

88TK05C-E is uesed in ABB Procontrol system. In conjunction with remote-bus coupling module 88FT05, 88TK05C-E is used for coupling a PROCONTROL station to the remotebus.
Moreover, the module controls all operations which are required to exchange data within a PROCONTROL station. The connection of the station bus to the PROCONTROL remote bus may either be of single-channel or dual-channeldesign (cf. block diagram for Connecting the stations’).
When installed in an autonomous station, the module per-forms the functions of a bus control module.

Features:
The module is equipped with
One standard interface (SS) with the station bus
One RS485 interface with remote-bus coupling module 88FT05
One module data interface with remote-bus couplingmodule 88FT05
One potential-isolated monitoring interface
One interface for dual-channel station-bus coupling
One input for operating the transmitter output stages inremote-bus coupling module 88FT05.

Ordering Information:

88TK05C-E GJR2393200R1220
88TK05C-E GJR2393200R1210
88TK05B-E GJR2393200R1210

88TK05C-E ABB Station-Bus Coupling Module

ABB Station-Bus Coupling Module

GJR2393200R1220 ABB Station-Bus Coupling Module

88TK05C-E GJR2393200R1220 ABB Station-Bus Coupling Module Images
